Description

[10" 8K Monochrome LCD] ELEGOO Saturn 2 adopts a 10-inch 8K mono LCD screen with an HD resolution of 7680x4320 and an ultra-fine XY resolution of 28.5 microns, outputting outstandingly detailed 3D models with a cure time of only 1-3s per layer. The scratch-resistant tempered glass above the LCD screen with 9H hardness for better light transmission and protection.

[43% Larger Printing Volume] With a build volume of 219x123x250mm / 8.62x4.84x9.84 inch and a 10” large mono LCD screen make the prototype size larger and the curing efficiency higher, you can print one larger model or multiple smaller models in a single batch.

[Fresnel Collimating Light Source] Fresnel collimating light source consists of 48 highly integrated UV LED lights that work with the FCL system Fresnel lens to emit a uniform light beam of 405nm wavelength with 92% light uniformity, excellent printing accuracy, and a more smooth surface finish.

[Reliable Printing Performance] The Z-axis is designed with dual linear rails and non-slip hexagon socket leveling screws for ultra-steady & accurate movement and remarkable printing performance. The sandblasted surface build plate provides much stronger adherence and PFA release liner with easier model removal and less release tension.

[Odor-free Printing Environment] The air filtration system with an activated carbon filter can absorb most of the resin odor, creating an odor-free fresh printing environment. Double heat-conducting copper heat tubes with faster heat transfer and better heat dissipation efficiency prolong the service life of 3D printers

Description

[Faster printing speed] Saturn 3D printer comes with an 8.9inch 4K Monochrome LCD with an HD resolution of 3840 x 2400, reducing the layer printing time to 1.5s-2s, which is 60% faster than Mars Pro yet still delivers outstanding printing results.

[Larger build volume] Saturn has a large printing volume of 192*120*200mm/7.55in*4.72in*7.87in, and you can print multiple full-sized models at the same time, which can dramatically improve your productivity.

[Higher precision and easier printing] Z-axis utilizes a double linear guideway structure, which can achieve steadier motion and greatly enhanced moving accuracy. With the ethernet port on the back and 4GB built-in data disk, Saturn now supports file transfer through your local area network, which is very handy for fast printing.

[Quality Prints and Consistent Success] Matrix light source consists of 54 UV LED lights with uniform light emission, ensuring superior print results and a more accurate printing size. The set screws on the build plate assure longlasting leveling, no need for frequent calibration, and the sandblasted surface provides a much stronger adherence, especially when printing large 3D models.

Description

• 【Faster printing speed】Saturn 3D printer comes with an 8.9inch 4K Monochrome LCD with an HD resolution of 3840 x 2400, reducing the layer printing time to 1.5s-2s, which is 60% faster than Mars Pro yet still delivers outstanding printing results.
• 【Larger build volume】Saturn has a large printing volume of 192*120*200mm/7.55in*4.72in*7.87in, and you can print multiple full-sized models at the same time, which can dramatically improve your productivity.
• 【Higher precision and easier printing】Z-axis utilizes a double linear guideway structure, which can achieve steadier motion and greatly enhanced moving accuracy. With the ethernet port on the back and a 4GB built-in data disk, Saturn now supports file transfer through your local area network, which is very handy for fast printing.
• 【Quality Prints and Consistent Success】Matrix light source consists of 54 UV LED lights with uniform light emission, ensuring superior print results and more accurate printing size. The set screws on the build plate assure long-lasting leveling, no need for frequent calibration, and the sandblasted surface provides a much stronger adherence, especially when printing large 3D models.
• We provide a 1-year warranty on the whole printer (4K LCD, FEP film, and tool kit excluded). Replacement parts will be shipped from the overseas warehouse to offer you quality and fast customer service.

Learn more about ELEGOO Saturn:

Parameters and Specification:

System: EL3D-3.0.1
Operation: 3.5 Inch Touch Screen
Slicer Software: Chitubox
Connectivity: USB
Technology: LCD UV Photocuring
Lightsource: UV Integrated LED lights (wavelength 405nm)
XY Resolution: 0.05mm(3840×2400)
Z Axis Accuracy: 0.00125mm
Layer Thickness: 0.01-0.15mm
Printing Speed: 30mm/h
Power Requirements: 100-220V 24V4A 96W
Printer Dimensions: 11.02in (L) * 9.44in (W) * 17.55in (H) 28cm(L) * 24cm (W) * 44.6cm (H)
Build Volume: 7.55in (L) * 4.72in (W) * 7.87in (H) 192mm (L) * 120mm (W) * 200mm (H)
Weight: 29.76 Lbs (13.5 Kg)

Finish Kit includes:

Saturn 3D Printer * 1
Build Platform * 1
Resin Tank * 1
U Disk * 1
Mask * 2
Gloves * 3
Metal Scraper * 1
Plastic Scraper * 1
User Instruction * 1
Funnel * 10
Measuring Cup * 1
Backup Screws * 1
Adapter 120W * 1
Tool Kit*1
Leveling Paper*1
Myminifactory 10% OFF Discount Card*1

Description

[4K Monochrome LCD] 6.6-inch 4K monochrome LCD screen with a replaceable anti-scratch tempered glass with 9H hardness for a better light transmittance at 4098 x 2560 high resolution, protecting the screen while restoring model details to the greatest extent.

[Powerful COB Light Source] Upgraded free-form surface COB lens consists of 36 highly integrated UV LED lights, paired with Fresnel lens to deliver an even beam of 405nm wavelength with 92% light uniformity for a more smooth surface finish and incredible printing quality.

[Large Build Volume] With a large build volume of 143×89.6×175mm (5.62×3.52×6.8 inches), you can print one large model or undergo batch printing in a single job, which saves your time and greatly improves your productivity.

[Designed for Reliability] Non-slip hexagon socket leveling screws work with the sandblasted oxide surface build plate for stronger adhesion and more stable printing. PFA release liner with less release tension for a higher printing success rate.

[Better Printing Experience] The air purifier with a built-in active carbon filter to effectively absorb and filter the resin odor and pungent fumes, giving you a fresh printing experience. Copper heat tubes and a powerful cooling fan with faster heat transfer and better cooling efficiency, extending the life span of 3D printer.

Description

[Excellent Industrial Design] Exquisite Appearance, industrial-grade design, panel integration offers convenient and neat steps.
[Excellent Printing Accuracy] Provides 30% improvement compared to the 2K screen of Mars 2. The finished print looks much closer to the model itself.
[Small Footprint but Large Printing Size] Mars 3 has a large printing volume of 89.6mm*143.36mm*175mm.
[Powerful COB Light Source] XY resolution: 0.035(4098*2560px); The heat sink system works 50% higher heat dissipation efficiency than ordinary sink.
[Solid Linear Rail and Sandblasted Build Plate] Works smoothly and silently; Model sticks firmly and not easy to fall off.

Description

• 【Fast Printing and fewer maintenance】Mars 2 Pro comes with a 6.08-inch monochrome LCD of 2K HD resolution and only takes 2 seconds per layer exposure to cure resin, which could significantly enhance your printing efficiency. Mono LCD has a much longer lifespan and stable performance during long-term printing thus saving your cost.
• 【Outstanding prints and ultra accurcy】Brand new light source structure provides more even UV light emission and working together with 2K mono LCD, the printing details and precision are greatly improved and the 3D printed models are fascinating.
• 【Sturdy build quality】CNC machined aluminum body makes Mars 2 Pro a very formidable machine. A newly-designed sandblasted build plate has a much stronger adherence during printing and enables consistent printing success. Built-in active carbon could absorb the fume of resin and offer you a refreshing printing experience.
• 【Multi language interface】Mars 2 Pro now supports 12 kinds of languages so customers across the world could operate the 3D printer more conveniently without barriers. The newly added 10 languages are Japanese, Dutch, Korean, French, German, Russian, Italian, Spanish, Turkish, and Portuguese.
• 【Warranty and Service】We provide a 1-year warranty on the whole printer and a 6-month warranty for the 2K LCD (FEP film is excluded). Mars 2 Pro comes with 2 extra FEP films for you to replace the original one if needed.

Technical Specifications System: EL3D-3.0.2 Slicer Software: ChituBox Technology: UV Photocuring Layer Thickness: 0.01-0.2mm Printing Speed: 30-50mm/h Z Axis Accuracy: 0.00125mm XY Resolution: 0.05mm(1620*2560) Build Volume: 5.08in(L)*3.15in(W)*6.30in(H) 129mm(L)*80mm(W)*160mm(H) Light Source: UV Integrated Light (wavelength 405nm) Languages: Chinese English Japanese Dutch Korean French German Russian Italian Spanish Turkish Portuguese Connectivity: USB Weight: 13.67lbs(6.2kg) Operation: 3.5 Inch Touch Screen Power Requirements: 100-240V 50/60Hz Printer Dimensions: 7.87in (L)*7.87in (W)*16.14in (H) / 20cm (L)*20cm (W)*41cm (H)

Description

• 【Fast Printing and less maintenance】Mars 2 comes with a 6.08-inch monochrome LCD of 2K HD resolution and only takes 2 seconds per layer exposure to cure resin, which could significantly enhance your printing efficiency. Mono LCD has a much longer lifespan and stable performance during long-term printing thus saves your cost.
• 【Outstanding prints and ultra accurcy】Brand new light source structure provides more even UV light emission and working together with 2K mono LCD, the printing details and precision are greatly improved and the 3D printed models are fascinating.
• 【Sturdy build quality】CNC machined aluminum body makes Mars 2 a very formidable machine. Newly-designed sandblasted build plate has a much stronger adherence during printing and enables consistent printing success.
• 【Multi language interface】Mars 2 now supports 12 kinds of languages so customers across the world could operate the 3D printer more conveniently without barriers. The newly added 10 languages are Japanese, Dutch, Korean, French, German, Russian, Italian, Spanish, Turkish, and Portuguese.
• 【Warranty and Service】We provide a 1-year warranty on the whole printer and a 6-month warranty for the 2K LCD (FEP film is excluded) .

Technical Specifications: System: EL3D-3.0.2Slicer Software: ChituBox Technology: UV Photocuring Layer Thickness: 0.01-0.2mm Printing Speed: 30-50mm/h Z Axis Accuracy: 0.00125mm XY Resolution: 0.05mm(1620*2560) Build Volume: 129mm(L)*80mm(W)*150mm(H) Light Source: UV Integrated Light (wavelength 405nm) Connectivity: USB Weight: 13.67lbs(6.2kg) Operation: 3.5 Inch Touch Screen Power Requirements: 100-240V 50/60Hz Printer Dimensions: 20cm (L)*20cm (W)*41cm (H)

2K Monochrome LCD ELEGOO Mars 2 MSLA 3D Printer comes with a 6.08-inch Monochrome LCD that has 2K HD resolution. It is four times longer in lifespan and two times faster in printing speed than the regular RGB LCD 3D printers, which means higher printing efficiency, more stable performance, and less maintenance.	Multi-language Interface The new operating system now supports 13 different languages: Chinese, English, Japanese, Dutch, Korean, French, German, Russian, Italian, Spanish, Turkish, and Portuguese, which significantly facilitates worldwide users to use Mars 2 more conveniently.	Replaceable Resin Tank With a green Plastic Tank, it adopts special engineering plastics, environmental protection and can be degraded. According to your needs, you can replace your printer tank to extend the life of your printer.
CNC Machined Aluminum Mars 2 is made of CNC machined aluminum, it has a very solid build quality and high durability like a reliable workhorse that always get its work done.	COB UV LED Light Source Excellent heat dissipation performance, high luminous maintenance rate, uniform light emission, and no spots. COB light source has proved itself to be a fantastic upgrade that ensures each printing comes out perfectly.	Chitu Box Slicer ChituBox has been a very helpful companion when you are using ELEGOO MSLA resin 3D printers from slicing .stl file to adding supports. With the latest 8-times anti-aliasing function, you can get a much smoother printing surface.

Description

• 【Fast Slicing Software】ELEGOO Mars comes with the latest version of CHITUBOX Slicing Software which gives you an extraordinary user experience. CHITUBOX takes only 1 minute to slice 30Mb .stl model files while the open-sourced slicing software would take up to 10minutes.
• 【Resin saving and Better Printing】CHITUBOX allows you to hollow out your model before slicing which could save your resin dramatically during the photocuring process. Equipped with 40W UV lights and using ELEGOO resin, you can get a better printing result.
• 【Smart and Convenient】3.5'' inch color touch screen equipped with the latest ELEGOO CHITUBOX 5.5 system makes it very easy for off-line printing. The build platform with steel ball balancing structure inside allows you to start printing within 5 minutes after assembly.
• 【High Precision and Resolution】ELEGOO Mars uses a 2560x1440 2K HD masking LCD to provide accurate printing with XY axis resolution of 0.00185inches / 0.047mm
• 【Warranty and Service】We provide a total one-year machine warranty (3-month warranty for FEP and 2K LCD consumable parts) and if you have any questions regarding product operation or software please feel free to contact us

ELEGOO has been manufacturing 3D printer components and parts since 2014 and with years of experience in 3D printing, we finally developed our own 3D printer using UV photocuring technology. We'd like to present to you our very first photocuring LCD 3D Printer- ELEGOO Mars.

Great industrial design and user-friendly system, we make ELEGOO Mars suitable for anyone to use even though you have never used a 3D printer before.

The semi-assembled printer will save your time setting up when you receive it and within 5 minutes you could start printing your first model we provided – 2 rooks, which could be easily sliced using our newly released CHITUBOX slicing software.

Description

Product Description

1. Print size: 220*220*300, the mainstream print size in the market, suitable for most users' needs;

2. V-wheel drive: The V-wheel is made of imported POM material, which has the advantages of ultra-quiet, high precision, and wears resistance. At the same time, the machine transmission mechanism is equipped with an eccentric isolation column, which can make up for the reduction of printing accuracy caused by long-term printing and wear of the V wheel;
3. Brand-name power supply: to ensure printing safety and low failure;
4. Intelligent fan control: After the machine has finished cooling down after printing, all fans will be turned off. Extend the life of the fan, solve the noise problem, and save power;
5. High-temperature hotbed: 250W hotbed, which can be quickly heated to 100°C to meet the temperature requirements of different materials for the hotbed;
6. Super large hand-tightened nut is ergonomic, easy, and convenient to level;
7. Silent printing: The machine adopts silent driving, printing without noise;
8. Support multi-language free switching: the machine supports Chinese simplified, Chinese traditional, English, French, Japanese, German, Russian, Italian and Spanish, and you can switch at will;
9. Frame type fuselage design: unique profile design, the machine is a frame structure, sheet metal casing, the machine is more stable;
10. Belt adjustment device: The X-axis adopts a belt adjustment device, which can easily adjust the belt tightness and ensure the printing quality;
11. Built-in power supply design: the power supply is installed inside the chassis, making it safer to use;
12. Material break detection and material shortage alarm: to avoid the machine running empty when the consumables are used up, resulting in material waste and model scrap;
13. Resume after power failure: avoid model scrapping due to power failure;
14. Resume printing at breakpoints: due to misoperation, nozzle misalignment, etc., can be used to resume printing on the interrupted model to continue printing;
15. Full-color 3.5-inch touch screen, sensitive and beautiful in operation;
16. Self-adhesive printing platform; the model can be easily taken without a shovel.
17.U disk printing, more convenient to use
18. High-end chip: STM32 high-end chip, more stable printing, more expansion possibilities

Scalable functions:
1. Automatic leveling
2. Laser engraving
3. Two-in-one-out two-color printing

Machine parameters

Product model: NEPTUNE X
Product name: FDM 3D printer
Rated power: 300W (heating bed power 250W, motherboard + fan, etc. about 50W)
Rated voltage: 115/230V 50/60Hz
Forming size: 220*220*300mm
Platform size: 235*235mm
Equipment dimensions: 625*472*507mm
Maximum nozzle temperature: 260℃
Maximum temperature of hotbed: 100℃
Net weight: 10.5KG

Description

Description

[Outstanding industrial design] CNC machined aluminum extrusion and semi-assembled parts for reliable build quality and easy setup. V-guide roller made of Germany POM material with ultra-silence, accurate motion, and excellent wear resistance during long term printing. 220X220X250mm printing size at ±0.1mm high precision. Supports multi-function extensions as well.

[Smarter 3D printing] Once a print is complete and the nozzle temperature drops below 50° Celsius, the cooling fans of the nozzle and the motherboard will automatically stop working, saving power and extending their lifespan. Resume printing from where it left after an unexpected power outage or faulty operations. MK8 extruder has wide material compatibility and equipped filament detection sensor will pause printing when filament runs out.

[Safe and stable power supply] 400Watt switched-mode power supply can better protect your printing from short circuit, overload voltage, or under-voltage situations. The 250Watt hotbed can be heated to 100° Celsius within 3 minutes under an average indoor temperature and keeps it stable to meet different filament materials' working requirements.

[Independent Dual Extruder Design] ELEGOO Dual Extruder FDM 3D Printer is Equipped with two all-metal extruders, it supports automatic dual color filament switching in a single nozzle. With two all metal gears equipped on each extruder, it provides better and more accurate prints.32bit motherboard with TMC2225 silent driver provides a quieter printing at 50db noise level and ensures consistent printing for 200 hours without any issues.

[Warranty and Service] We provide lifetime technical support with fast response in customer service for Pre-owned Machines.

Description

• 【Outstanding industrial design】CNC machined aluminum extrusion and semi-assembled parts for reliable build quality and easy setup. V-guide roller made of Germany POM material with ultra-silence, accurate motion, and excellent wear resistance during long-term printing. 220X220X250mm printing size at ±0.1mm high precision. Supports multi-function extensions as well.
• 【Smarter 3D printing】Once a print is complete and the nozzle temperature drops below 50° Celsius, the cooling fans of the nozzle and the motherboard will automatically stop working, saving power and extending their lifespan. Resume printing from where it left after an unexpected power outage or faulty operations. MK8 extruder has wide material compatibility and equipped filament detection sensor will pause printing when filament runs out.
• 【Safe and stable power supply】400Watt switched-mode power supply can better protect your printing from short circuit, overload voltage, or under-voltage situations. The 250Watt hotbed can be heated to 100° Celsius within 3 minutes under an average indoor temperature and keeps it stable to meet different filament materials' working requirements.
• 【Intuitive and user-friendly experience】Multi-language user interface show the model preview and real-time printing progress. Large rotary nuts make leveling easier. The hotbed holds a replaceable fiberglass sheet with a matte Polycarbonate surface, which has a stronger adhesion and allows you to remove models without any hassle. 32bit motherboard with TMC2225 silent driver provides a quieter printing at 50db noise level and ensures consistent printing for 200 hours without any issues.
• 【Warranty and Service】We provide a 1-year warranty on the printer (nozzle and build plate sheet excluded) and lifetime technical support with fast response in customer service. If you need a replacement part, we will deliver it to you from the local warehouses giving you a better after-sales experience.
